Choosing your Curtain Track Width

The width of the curtain track should extend past your window this allows for the curtains to stack back away from your window and allow light in.

Measure your recess and then add on 15cm on either side. For acoustics , we recommend further to fully cover the window and the surrounding area. In our test we added an additional 30cm to the width and also made the curtain floor length.

Wave curtains, for every 100cm of track the curtains will stack circa *18cm

Eyelet curtains, they will stack back circa 10cm per *70cm of track width

Pencil Pleat will stack approx 25% of the track width. eg. 210cm track will stack 52.5%

* all dependent on thickness of fabric

Selecting your Curtain Drop

Where to Measure From for Different Type of Curtains

How to Measure for Blinds going Inside the Recess

• Measure the exact width of the recess in three places; at the top of the recess, in the centre of the recess and near the bottom - then take the  smallest size.
• Measure the exact drop of the recess in three places on the left hand side of the recess, in the centre of the recess and on the right hand side of the recess - then take the smallest size.
• We will take one cm off the finished width size you have given us, to allow for the blind to pull up and down easily.
• Double check your measurements
• Cord Safety - Mounting Height - We ask for the mounting height of your blinds to allow for the cord to be 150cm off the ground. If mounting at 210cm This is what you enter in the Fitting height box. We make a deduction to ensure the cord is 150cm from the floor. Thus the cord loop will be 60cm

How to Measure Outside of the Recess

• Measure the recess in 3 places on the width and also 3 places on the drop. Take the widest measurement.
• Measure the width of the actual recess plus an additional amount – Usually from 7cm-15cm whatever you think looks appropriate. This is for overlap.
• Measure the exact drop of the recess. The blind would be fitted above the recess, so check the space above and add an amount on to the drop – usually from 7-15cm
• These sizes you have taken will be the size of the finished blind.

• Double check your measurements
• Cord Safety - Mounting Height - We ask for the mounting height of your blinds to allow for the cord to be 150cm off the ground. If mounting at 210cm This is what you enter in the fitting height box. We make a deduction to ensure the cord is 150cm from the floor. Thus the cord loop will be 60cm

Cubicle Tracks you have to measure with right angles from wall to wall where you want the track to go

Draw your room on a piece of paper with a sky view

Now measure from the wall to wall for straight tracks,

L Shape Tracks Measure to a point on the floor and mark with a piece of tape. Then for the other sides measure from the other wall to that point.

Always check for obstructions and fitting issues you may need to work around
